YS903
|
Item No. |
YS903 |
|
Brand |
Yasen |
|
Dimension |
1580*370*100mm,100-230VAC |
|
Frequency |
8.2MHz |
|
Detect distance |
Soft label:1.3-1.5m |
|
Hard tags:2.0-2.4m |
|
|
Material |
Aluminum alloy |
|
Feature |
High detect sensitivity and low mistake |
|
PCB board |
4600/4800/4900 |
|
MOQ |
1 set |
|
OEM & ODM |
Support |
|
Certification |
CE, SGS, ISO9001 |
|
Packing way |
1 pc/carton |
|
Packing size |
1600*500*140mm |
Instructions For Use
Installation steps:
1. Confirm that it is working properly: Connect the security door at the location to be installed, test the effect and whether there is a false alarm. Can be installed after the test is normal
2. What should I do if I encounter environmental disturbances: 1 computer debugging change settings 2 contact us online help 3 remote control debugging
3. Fixed installation: After installation, confirm that the connecting cable is fixed with expansion screws or covered with floor tiles. Note: It is best to complete the installation by professional installers.
4. Installation complete the final test: whether the test is functioning properly and the effect is as good as interference or poor effect. You can use the computer to debug or contact our engineers for one-on-one assistance and remote control debugging.
Installation note:
1. Do not install the security door on the wall, 15 cm away from the wall.
2. The security door must be tested for several hours before installation without any problem.
3. Hanging clothes need to be more than 1 meter away from the security door, and the shelf needs to be more than 1 meter away from the security door.
4. The intermediate cable is covered with a wire slot or placed under the floor tile.
The body is made of high quality ABS material, resistant to low temperature、impact, heat resistance, chemical resistance, louder speaker.
Large alarm light, LED concentrating technology, large red warning light, outstanding effect.
Insurance tube: The main board of the access control system uses the fuse to realize the secondary protection of the circuit. Multiple protection, if the voltage is too high or the current is too large, the motherboard will not burn out.
The positive and negative poles are connected to the wrong anti-burnout motherboard: the access control system uses an advanced self-protection circuit board, and the positive and negative poles are connected with an eye-catching LED light to remind them, and effectively protect themselves from burning.
Intelligent digital detection, easy to deal with the surrounding complex environment, fast alarm, easier to install and test maintenance. The sensitivity is adjustable.
Thickened metal base for more stability and peace of mind.
Fully matched connector: The access control system adopts the international standard connector, the hole position and the pin are fully matched, which is convenient for the customer to install and avoid the installation error.
Our EAS products are widely used in.many scopes, such as supermarket, lothing store, cosmetic shop, digital shop, library and shoes shop.By serving for large customergroups from different areas, we have engaged in offering full set of suitable EAS anti-theft solution Enhance great experience for many years, we are making effort to provide more better service.
◎Professional
The core management team and technical team of the company have more than18years experience in EAS industry. From order to production we show you the production process. We commit that quality is one of oul core values. All our products are produced and developed according to current norms and standards, and thoroughly tested.
◎ODM and OEM
we are in a position to accept orders against clients' need specifying design, specifications and packing requirements. We also provide OEM service.
◎Service
Our company supports trade assurance - a free service that protects your interests in all aspects of payment, quality and shipment.
